Prensas de rodillos especiales para la industria química y mineral.
Con rodillos hidráulicos para grandes rendimientos y altas fuerzas de prensado.
Series ARC MS y ARC CS
Kompaktor ARC MS
The specialist for customer-specific special solutionsKompaktors from the ARC MS series compress powder to granulate or briquettes.
This process is described as compaction or briquetting.
The rollers of this Kompaktor are of a mill shaft design which makes the machines very robust and durable.
The machine series ranges from smaller machine with 300 mm roller diameter for chemical products to machines with up to 1.100 mm roller diameter and throughputs of up to 120 t/h– for mineral applications.
Technical details
- Working width of 80 - 1,000 mm
- Drive unit of 11 kW to 800 kW
- Gravity fed
- Gravity fed for optimal throughput capacity
- Throughput capacity of 0.5 – 120 t/h
- Wear-protected construction
- Segmented rollers, solid rollers or roll tyres
- Vacuum de-aeration in the case of light products
- Stainless steel construction optional
- Gas-tight housing
- Roller cooling optional
Machine sizes
| Kompaktor ARC MS | 36 | 60 | 85 | 180 | 300 | 450 | 600 | 800 | 1000 |
|---|---|---|---|---|---|---|---|---|---|
| Press force (kN) | 360 | 600 | 850 | 1800 | 3000 | 4500 | 6000 | 8000 | 10000 |
| Roller diameter (mm) | 300 | 400 | 520 | 520 | 712 | 850 | 1100 | 1100 | 1400 |
| Throughput in t/h | 0,5 - 1,2 | 0,8 - 5 | 2 - 8 | 5 - 15 | 8 - 30 | 20 - 80 | 80 - 120 | 100 - 200 | 150 - 250 |
The throughput is dependent on the product.
Kompaktor ARC CS
Maintenance-friendly and robustWith the Kompaktor ARC CS 25 powder is process to granulate or briquettes. This process is described as compaction or briquetting.
Due to the cantilever bearing the Kompaktor ARC CS 25 is particularly easy to maintain and this with 25 tonnes of press force!
The Kompaktor ARC CS 25 is particularly suited for the laboratory and for small product amounts. Made for frequent product changes and abrasive products because the rollers can be easily replaced.
